Toshiba PVT-375BT Convex Array Transducer Probe 6Mhz Hospital Supplies

Knowledge point

The Canon Toshiba PVT-375BT Curved Array transducer has a frequency range of 1.9 MHz. - 6.0 MHz. and supports the following applications: Abdominal. The Toshiba PVT-375BT transducer is compatible with Toshiba Aplio 50 (SSA-700A); Toshiba Aplio 80 (SSA-770A); Toshiba Aplio XG (SSA-790A); Toshiba Aplio 300 (TUS-A300); Toshiba Aplio 400 (TUS-A400); Toshiba Aplio 500 (TUS-A500); Toshiba Xario (SSA-660A) ultrasound systems.

Multi-frequency probe

Multi-frequency probe is a new development of pulse-echo transducer. The probe can send out several different ultrasonic pulses, to cover the near field with high-frequency ultrasound, intermediate-frequency ultrasound to cover the transition zone between the far and near fields, and low-frequency ultrasound to cover the far field. The unit multi-frequency probe is to bond multiple layers of piezoelectric ceramics (or polymer piezoelectric materials) to each other, and lead wires from the electrodes between each layer to obtain multiple frequency ultrasonic pulse emission through exciting different layers. The digital coding of the multi-frequency probe is simple but easy to lose the signal.

Other Toshiba probes we can offer:
