Aloka Prosound 2 EP546900EE Backplane Board Ultrasound part

Aloka Prosound 2 EP546900EE Backplane Board

About Aloka Prosound 2

1. Product Features
Sophisticated and portable: Prosound 2 is compact and lightweight, which is convenient for users to carry around and suitable for various inspection environments.
Excellent image quality: This product integrates the excellent imaging technology of Aloka Prosound series products, such as enhanced pure harmonic detection, multiple frequency-selective imaging technology, boundary enhancement function, etc., which can provide high-quality ultrasound images and meet clinical requirements for image clarity and detail.
Diversified probes: Prosound 2 supports a variety of probes, including abdominal/obstetrics and gynecology convex array probes, small organs/peripheral vascular high-frequency array probes, cardiac phased array probes, etc., which can meet different parts and different inspection needs.
Efficient storage and management: In a digital environment, Prosound 2 can efficiently store, replay and manage data, improving work efficiency.
Quick start and inspection: This product has a quick start function, and the probe supports efficient inspection, which can quickly enter the working state and shorten the inspection time.
2. Technical Specifications
Although the specific technical specifications may vary depending on the product model and configuration, Prosound 2 generally has the following basic technical specifications:

Scanning depth: Scanning depth may vary depending on different probes and settings.
Resolution: High-resolution images can display more detailed information.
Dynamic range: A larger dynamic range can display more grayscale levels, thereby improving the contrast of the image.
Scanning frame rate and color display frame number: Higher scanning frame rate and color display frame number can provide smoother and clearer images.
3. Application areas
Prosound 2 is widely used in the field of clinical ultrasound diagnosis, including but not limited to the following aspects:

Abdominal ultrasound: used to examine diseases of abdominal organs such as the liver, gallbladder, pancreas, and spleen.
Obstetrics and gynecology ultrasound: used to examine obstetrics and gynecology-related issues such as the fetus, placenta, and amniotic fluid.
Cardiac ultrasound: used to examine the structure and function of the heart, as well as heart-related diseases.
Superficial tissue and small organ ultrasound: used to examine diseases of superficial tissues and organs such as the thyroid, breast, and lymph nodes.

About Aloka Prosound 2 Backplane Board

1. Backplane Board Overview
Definition: The backplane board is an important component inside the ultrasound diagnostic instrument. It is usually located at the core of the device and is responsible for connecting various functional modules, such as the probe interface, image processing module, data storage module, etc.
Function: The main function of the backplane board is to provide signal transmission and power distribution between various modules to ensure that the entire device can work normally.
Features: Backplane boards usually have high integration and reliability to meet the requirements of ultrasound diagnostic instruments for high precision and high stability.
2. About Aloka Prosound 2 EP546900EE Backplane Board
Compatibility: This backplane board is designed specifically for the Aloka Prosound 2 ultrasound diagnostic instrument, so it has good compatibility with other Aloka Prosound 2 series devices or components.
Maintenance: Since the backplane board is one of the core components of the ultrasound diagnostic instrument, its maintenance and replacement usually need to be performed by professional technicians. If users encounter problems related to the backplane board, it is recommended to contact the equipment manufacturer or a professional repair service provider for resolution.
3. Precautions
Safety: When handling the backplane board or other internal components of the ultrasound diagnostic instrument, be sure to follow the equipment manufacturer's safety operating procedures to prevent electric shock or other safety accidents.
Professionalism: Since the ultrasound diagnostic instrument belongs to the category of medical equipment, the replacement and maintenance of its internal components usually need to be performed by professional technicians with relevant qualifications and experience.

Wide variety of parts, over 1000 pcs in stock, involved in popular brands and systems(GE, Hitachi Aloka,Philips,Siemens,Toshiba,Esaote......)

Experienced & specialize after-fix technical support team.
