Aloka Alpha10 Control Panel L-KEY-84G Ultrasound Spare Part

Aloka Alpha10 Control Panel L-KEY-84G

About Aloka ALPHA10

Aloka Alpha10 is an ultrasound instrument with revolutionary front-end processing technology. Its image quality is excellent and provides strong support for clinical diagnosis and treatment. The following is a detailed introduction to the product:

Image quality:
Alpha10 uses revolutionary front-end processing technology to achieve revolutionary improvements in image spatial resolution and contrast resolution.
Through complete crystal control technology, precise delay control and composite array probes, the clarity and accuracy of the image are significantly improved.
Front-end processing technology:
Complete crystal control technology: The pioneering composite pulse wave generator controls the vibration and stop of the ultrasonic chip from beginning to end, achieving a significant improvement in image spatial resolution and contrast resolution.
Precise delay control: High-precision time delay control effectively suppresses side lobe artifacts and greatly improves the signal-to-noise ratio.
Composite array probe: Combining the latest materials science and probe cutting technology, it achieves three-dimensional matrix focusing and significantly improves spatial resolution and contrast resolution.
Data management and compatibility:
Alpha10 complies with the DICOM3.0 standard and can realize network storage, printing and transmission, and facilitates the sharing of information and data with medical information collection systems and hospital information systems (HIS).
The processing and analysis of raw radio frequency data can enable the ultrasound system and data analysis to reach the micron level, providing strong support for accurate diagnosis.
Clinical application:
Alpha10 is widely used in multiple clinical fields such as abdomen, obstetrics and gynecology, superficial surgery, breast, and cardiovascular, providing doctors with a comprehensive diagnostic tool.
Especially in the early detection of vascular lesions, Alpha10's vascular echo tracking technology E-TRACKING can be accurate to 0.01mm, making it possible for early detection and treatment of diseases such as arteriosclerosis.
User-friendliness:
The operation interface of Alpha10 is designed to be simple and clear, making it easy for doctors to use and operate.
It provides a variety of forward-looking analysis functions, such as re-adjustable two-dimensional, color and Doppler gain after image freezing, providing doctors with more diagnostic methods.

Aloka Alpha10 Control Panel

The control panel of Aloka Alpha10 is the core operating area of ​​the device, allowing doctors to perform various detailed operations and settings during the examination. The following is a detailed introduction to the control panel:

Layout and keys:
The control panel has a reasonable layout and clear buttons, making it easy for doctors to operate quickly and accurately during the examination.
The buttons are rich in functions, including power switch, image adjustment (brightness, contrast, gain, etc.), mode selection, storage/playback and other common functions.
Adjustment function:
The image adjustment function allows doctors to fine-tune the image quality to obtain the best display effect.
Adjustment of gain, brightness, contrast and other parameters can adapt to different examination needs and patient conditions.
Mode selection:
There is a mode selection button on the control panel, and the doctor can select the appropriate examination mode according to the examination site and clinical needs.
Different inspection modes correspond to different image parameters and diagnostic tools, providing doctors with comprehensive diagnostic support.
Storage and playback:
The storage function allows doctors to save the current ultrasound image for subsequent analysis and diagnosis.
The playback function allows doctors to review previously stored images for comparison and analysis.
Other features:
There may also be other additional function buttons on the control panel, such as probe selection, image zoom in/out, image rotation/translation, etc., to meet the different needs of doctors during the examination.

Wide variety of parts, over 1000 pcs in stock, involved in popular brands and systems(GE, Hitachi Aloka,Philips,Siemens,Toshiba,Esaote......)

Experienced & specialize after-fix technical support team.
